Horton 700 Mobile Generator – 560 kW / 700 kV / 1520 Amps at 240 V / 42 Hours

DAE Pumps Horton 625 Mobile Power Generator

Horton 700 Mobile Generator – 560 kW / 700 kV / 1520 Amps at 240 V / 42 Hours

The DAE Pumps Horton 700mobile generators are the industry’s most robust generators. The Horton mobile generators are essential tools for worksites with moving equipment and operations with multiple projects and locations, offering a full range of powers. The Horton 700 provides 560 kW / 700 kVA power with 42 hours of continuous runtime.

The DAE Pumps Horton mobile generators are the industry’s leading diesel generators for supplying uninterrupted power with exceptional performance for any electrical power need. Reliable and durable Horton 700 power generators are tested and engineered for long-life performance. These industry-best mobile power generators cover all types of power needs from construction and mining sites, to power plants, events, and critical segments.

Horton 700 industrial power generators are packed with features that make operating, transporting, and maintaining as easy as possible. These generators consist of an alternator, diesel engine, cooling system, electrical distribution, and control systems – all enclosed within a sound attenuated enclosure fabricated from powder-coated galvanized steel. Take them wherever you need to go for mobile and portable access to power.

The Horton 700 is part of the Horton Series Generators which offer a variety of sizes, power, configurations, and more to match your needs.

Get Pricing

Horton 700 Mobile Generator

Features:

  • Double Runtime: Over 40 hours of fuel tank capacity provides longer runtime between fill ups and optimum site autonomy.
  • Corrosion Resistant Canopy: 1000-hour salt test.
  • Quick Power Stability: Reach stable power in less than 6-seconds.
  • Dual Stage Filtration: Dust separation system and heavy-duty filtration system prolongs the life of your generator.
  • Safe and Easy Movement: Adaptable to whatever your jobsite demand.
  • Easy Access and Service: Large doors provide easy access.
  • Integrated Door Sealing System: Provided watertight and soundproof seal.
  • Multi-Voltage Switch: Modify voltage output in seconds.
  • Easy-fill System: Exterior simple fill system for fuel and DEF.

Generator Specifications:

1ated Prime Power 3Ø –  560 kW / 700 kVA

3- Phase
Amp Capacity @ 480V – 842 Amps
Amp Capacity @ 240V – 1520 Amps
Amp Capacity @ 208V – 1525 Amps
1-Phase
Amp Capacity @ 240V – 1083Amps
Amp Capacity @ 120V – 1083 x 2 Amps

Runtime – 42 Hours

Convenience Receptacles:
2 x NEMA 5-20R, 3 x 125/250V, 3 x 125/250V 50A CS6369

Power Distribution – Terminal Board 5 Wire

Diesel Engine

Volvo Tier 4 Final, turbo charged, intercooled, six-cylinder, liquid-cooled diesel engine provides ample power to operate the generator continuously at full-load. It meets all US EPA, CARB and Environment Canada exhaust legislations with Tier 4 Final compliance. The engine utilizes a Selective Catalytic Reduction (SCR) and Diesel Exhaust Fluid (DEF) to meet final Tier 4 emissions. All functionality of the engine is monitored automatically on the controller.

The engine has the capability to start the generator at 14°F (-10°C) with standard glow-plug aid. Cold start options are available for machine
starting for down to -13°F (-25°C).

DAE Pumps Horton 330 Mobile Power Generator

Power Distribution

The main power is connected from the alternator through a 4-position voltage selector switch to the main power cubicle. The cubicle incorporates all power distribution, controls, sensing and protection devices.

  • 4-position Voltage Selector Switch(VSS)
  • Current transformer x 3 (1 each leg)
  • Single main breaker w/shunt trip
  • Individual breakers for each receptacle
  • Convenience receptacles located on outside of unit for easy access
  • Terminal board for hard wiring
  • Cam-Lock external quick connect (available as option)
  • External emergency stop switch (recessed)
  • Neutral bonded to Ground with a removable bonding link accessible in the control cubicle.



Horton 700 Power
Horton 625 Receptacles

Alternator

DAE Pumps Horton 700 power generators use alternators built for heavy-duty continuous application with marine winding protection. We use Leroy Somer alternators with AREP excitation systems for superior starting capabilities. The AREP system uses two independent auxiliary windings located in the main stator to send supply voltage to the AVR.

Control System

The Horton 700 control system uses a fully diagnostic DeepSea 7310 ECU controller with a large 3-inch display, that is intuitive and easy to operate with all functions conveniently at your fingertips. The controller manages the engine ECU operating system and several safety warnings and shutdowns on various parameters.

Horton Controller
  • Complete user-friendly configuration and easy-to-use high-level system control & monitoring
  • Clear accurate power measurement information
  • Protects generator against overload
  • CAN & alternator speed sensing
  • 3-phase generator sensing
  • Large backlit display

Factory Options Available (extra)

  • Qc 4004 controller with 7 capacitive touch screen.
  • Paralleling with TDU (touch display unit)
  • Skid mounted
  • Cold Weather Option
  • Spare tire
  • Stabilizer jacks
  • Toolbox
