Tampa 6110 Submersible Slurry Pumps – 6″ / 977 GPM / 15 HP
DAE Pumps Tampa 6110 Submersible Slurry Pumps are rugged, reliable, and cost-effective pumps for transporting slurry, sand, and a variety of other abrasive materials. The DAE Pumps Tampa 6110 offers an open stand or strainer, and agitator that provides high suction and movement of solids up to 1.4-inches through a 6-inch discharge. The ergonomic Tampa 6110 submersible slurry pumps transfer solids and liquids at a flow rate of up to 977 GPM and with 15 HP.
Uniquely designed, the robust DAE Pumps Tampa 6110 submersible slurry pump is built from rugged cast iron construction with a high chrome iron impeller, agitator, and wear plate that provides durability and impact resistance in rough conditions. These robust submersible slurry pumps serve a wide range of slurry transport applications like mining, quarrying, construction sites, and other demanding industries.
The DAE Pumps Tampa 6110 is part of the Tampa Series Submersible Slurry Pumps, which offer a variety of other sizes, flow rates, and speeds.
Tampa 6110 Submersible Slurry Pumps
- Watertight Cable Entry
- Top Discharge and Side Flow Design
- Motor Protector
- Submersible 4-Pole
- C3 Ball Bearings and Hardened SS Shaft
- Double Mechanical Seals
- Extra Protection for Mechanical Seals and Shaft
- High Chrome Iron Impeller, Agitator, and Wear Plate
- Hardened Pump Volute
- Rugged Cast Iron Construction
- Food Grade Lubricant
Discharge Size: 6″ (150 mm)
Max Capacity: 977 GPM (266 m³/h)
Solid Handling: 1.4” (35mm)
Max Head: 72’ (22m)
Max Power: 15 HP (11 kW)
Max Operating Speed: 1750 RPM
Type: Electric Submersible Pumps
Classification: IP 68
Type: Induction Motor
Poles: 4 Pole
Insulation: Class F
Protector: Circle Thermal Protector
Start Method: D.O.L.
Lubricant: Food Grade (ISO VG32)
Type: Double Mechanical Seal
Desc.: Silicon Carbide VS Ceramic / Carbon
Impeller Type: Opened
Bearings: C3 Shielded ball bearings
Type: PVC (CSA Certified) / H07BQ-F
Length: 33’ (10m) or longer upon request.
Pump Casing: Ductile Iron
Impeller: Chromium Iron
Motor Frame: Gray Iron
Motor Shaft: Stainless Steel
Wear Plate: Chromium Iron
Agitator: Chromium Iron
Max. Liquid Temp.: 104˚F (40˚C)
Max. Sub. Depth: 66′ (20m)
pH Range: pH 5 – pH 8
