Tampa 475 Submersible Slurry Pumps – 4″ / 655 GPM / 10 HP

DAE Pumps Tampa 475 Submersible Slurry Pumps

Tampa 475 Submersible Slurry Pumps – 4″ / 655 GPM / 10 HP

DAE Pumps Tampa 475 Submersible Slurry Pumps are rugged, reliable, and cost-effective pumps for transporting slurry, sand, and a variety of other abrasive materials. The durable DAE Pumps Tampa 475 offers an open stand or strainer, and agitator that provides increased suction and movement of solids up to 1-inch through a 4-inch discharge. The ergonomic Tampa 475 submersible slurry pumps transfer solids and liquids at a flow rate of up to 655 GPM and with 10 HP.

Uniquely designed, the robust DAE Pumps Tampa 475 submersible slurry pump is built from rugged cast iron construction with a high chrome iron impeller, agitator, and wear plate that provides durability and impact resistance in rough conditions. These robust submersible slurry pumps serve a wide range of slurry transport applications like mining, quarrying, construction sites, and other demanding industries.

The DAE Pumps Tampa 475 is part of the Tampa-Series Submersible Slurry Pumps, which offer a variety of other sizes, flow rates, and speeds.



Tampa 475 Submersible Slurry Pumps


  • Watertight Cable Entry
  • Top Discharge and Side Flow Design
  • Motor Protector
  • Submersible 4-Pole
  • C3 Ball Bearings and Hardened SS Shaft
  • Double Mechanical Seals
  • Extra Protection for Mechanical Seals and Shaft
  • High Chrome Iron Impeller, Agitator, and Wear Plate
  • Hardened Pump Volute
  • Rugged Cast Iron Construction
  • Food Grade Lubricant
DAE Pumps S-Series Sewage Treatment


Discharge Size: 4″ (100 mm)
Max Capacity: 655 GPM (178 m³/h)
Solid Handling: 1” (25mm)
Max Head: 61’ (18.5m)
Max Power: 10 HP (7.5 kW)
Max Operating Speed: 1750 RPM
Type: Electric Submersible Pumps
Phase: 3-Phase
Classification: IP 68
        Type: Induction Motor
        Poles: 4 Pole
        Insulation: Class F
        Protector: Circle Thermal Protector
        Start Method: D.O.L.
Lubricant: Food Grade (ISO VG32)
Shaft Seal:
Type: Double Mechanical Seal
Desc.: Silicon Carbide VS Ceramic / Carbon
Impeller Type: Opened
Bearings: C3 Shielded ball bearings
        Type: PVC (CSA Certified) / H07BQ-F
        Length: 33’ (10m) or longer upon request.
        Pump Casing: Ductile Iron
Impeller: Chromium Iron
Motor Frame: Gray Iron
Motor Shaft: Stainless Steel
Wear Plate: Chromium Iron
Agitator: Chromium Iron
Max. Liquid Temp.: 104˚F (40˚C)
Max. Sub. Depth: 66′ (20m)
pH Range: pH 5 – pH 8



Get turnkey solutions that include dredge hoses, slurry flow meters, power units, and more. Choose from multiple sizes of slurry hoses for the transferring of materials, wireless flow meters for measuring the flow rate in gallons per minute of liquid, and power units for operation. Parts are always in stock and available for immediate shipping to anywhere in the US and the world.


Tampa 475 Submersible Slurry Pumps

Dredging Applications

    DAE Pumps Growler 5000 is ideal for removal of sediment, contaminants, tailing and cleaning to provide for safer navigation, reformation of shorelines and seafloor and other use at:
  • Dams
  • Ports
  • Marinas
  • Rivers
  • Canals
  • Lakes
  • Ponds
  • Oceans
  • Channels
